AC smoke detector SA12IL

AC smoke detector SA12IL

AC smoke detector SA12IL

    Share:

HISELEC smoke detector were designed with the most modernized structure and appearance.

We have both AC type and DC type, which also with 10 years long lifespan.

General idea it has below advantage:

1.Environmental protection;

2.Affordable and easy to user installation;

3.High Reliable;

4.Easy Integration;



Description

Product type SA12IL
Description AC main powered with 3V lithium replaceable 10 years battery backup.

HISELEC had accumulated rich technical experience on hardware technology, application software, products reliability and circuits design. We have gained quantities of patents for utility models

and patent for invention. HISELEC have a top and professional strong R&D team with more than 10 experts, including industry design, hardware, software, firmware,  structure, APP, ID and testing.

Our experts had been worked on respective industries more than 15 years in world-renowned brands and companies.  HISELEC is regarded as one of the rapid growing company in security and  smart industry.

And will continue developing new technology and products to meet the market demands and customer customization.

We are ready to protect the safety of the families and to create a smart comfortable living space for you.


HISELEC is actively to promote the international development strategy and establish a close working relationship with many international brands and Institutions of higher learning in China.

We will seize the opportunity to innovate our own products continuously and accelerate of  internationalization to achieve economies of scale and become a leading ODM/OEM manufacturer.

We are always looking for sincere and mutual cooperators all over the world. Welcome to read our catalogue to find out your interested  products and known more about our company.

Please do not hesitate to contact us.


Outstanding:
1. 3V lithium replaceable battery power supply with I/O port, ultra-low power consumption, 10-years-lifespan;

2. Standby power consumption is lower than 0.1VA, which will save more than 97% energy than other AC smoke alarms (normal 7VA) in the market.

3. All-digital detection technology design can avoid false alarm caused by over 90% electronic noise.

4. Wire interconnection up to 48 pieces.



Product Feature:
1. Dual power supply, 10 years long-life replaceable battery backup even without AC power;
2. Up to 48 pieces interconnection in a network by wire;
3. Standby power <0.1VA;
4. Digital technology, less false alarm, 5 years warranty;
5. I/O port for interconnection;

Technical


Product Type SA12IL
Certificate TUV, CE, RCM
Supply Mains 200-240Vac with 3V DC replaceable Battery Backup
Battery Type CR123 or CR2/3 Lithium 1500mAh Battery
Battery Life >10 years
Operation Current AC max 0.02A
Detection Type Smoke
Interconnectable Hard wires by I/O ports up to 48 pieces
Function Available Hush Function
Self-test of smoke detection
Local alarm
Control Type Button for test/ hush function
Sound Pattern ISO8201
Smoke Sensitivity 0.1-0.18dB/m
Directional Depending <1.4
Response Time Approx. 8s
Noise Level Minimum 85 dB at 3m
Time Delay Range 8-15 min. for hush
Local Signal Sound: Alarm
Sound: Signal
Visual: 1 green LED light for Power indicator.
Visual: 1 red LED light for warning and low battery.
Type Of Installation Indoor
Device Mounting Surface
Fixing Mode By screws
Warranty 5 years
Diameter 120 mm
Height 40 mm
Ambient Air Temperature For Operation 0......45 C°
Relative Humidity 10......92%
Standards To Comply EN14604-2005, AS3786-2014
